[tab-title-1]Motor Specifications [tab-title-end-1] [tab-content-1]
750W Nominal 1200W Max Power, 50km/h
Front Hub Motor
Available Rims
27.5''

48V 500W/750W Geared hub motor kit
Motor weight 4kg
Motor peak torque 100Nm
Suitable for utility or heavy duty bikes
Not recommended for commuters or urban use
 Description:
1200W of max power using 48V 25A controller, 50km/h, front hub motor, small size with simple structure, light weight and long life, super power, high efficiency, beautiful, high speed motor with gear, drive is very free and fluent, best choice for Li-ion battery on e-bike for rough road, higher weights and higher grade-ability.
 Motor Type: DC Brushless Geared Hub Motor
Motor Power: 750W
Voltage: 48V
Max Torque: 125Nm @25A
Efficiency ≥80%
36 Spokes
Flange for disc brake
Waterproof connector
Axle=100mm, Diameter=177mm.
Weight=4kg
Phase angle 120 degree
Manufacturer: MXUS
Waterproof and protection grade: IP54
Noise level 55dB
CE, EN15194 certifications
Material:
Wheel, A356 Aluminum
Magnet, 38SH
Wire(winding), QZ-3/155
Iron core, DW470
Bearing, C&U
Rear Hub Motor
Available Rims

27.5''
29''
700C

48V 500W/750W Rear Geared hub motor kit
Motor weight 4kg
Motor peak torque 100Nm
Suitable for utility or heavy duty bikes
Not recommended for commuters or urban use

Description:
1200W of max power using 48V 25A controller, 50km/h, rear hub motor, small size with simple structure, light weight and long life, super power, high efficiency, beautiful, high speed motor with gear, drive is very free and fluent, best choice for Li-ion battery on e-bike for rough road, higher weights and higher grade-ability.
Only accepts cassettes
 Motor Type: DC Brushless Geared Hub Motor
Motor Power: 750W
Voltage: 48V
Max Torque: 125Nm @25A
Efficiency ≥80%
36 Spokes
Flange for disc brake
Waterproof connector
Axle=135mm, Diameter=177mm.
Weight=4kg
Phase angle 120 degree
Manufacturer: MXUS
Waterproof and protection grade: IP54
Noise level 55dB
CE, EN15194 certifications
Material:
Wheel, A356 Aluminum
Magnet, 38SH
Wire(winding), QZ-3/155
Iron core, DW470
Bearing, C&U



[tab-content-end-1]
[tab-title-2] Battery Specifications [tab-title-end-2] [tab-content-2]
Lizard style ENVO Li-Ion battery pack in stylish thin ABS case with auto connect socket, with charge indicator, security lock and accessories.
Lizard Battery 48V 17.5Ah
Lizard style down tube mounting Li-Ion pack in stylish thin ABS case with auto connect socket, with charge indicator, security lock and accessories.
The Lizard battery is a battery you can mount on bike’s frame 2 water bottle bolt mount. This is the thinnest battery case for suspension frames or small size frames. Check the bicycle frame down tube geometry then select.  The battery can be locked to its support or un-lock and slide out to remove.
Li-Ion 48V  17.5Ah
Energy : 840Wh
Max Power: 1700W
Standard recharge time 8 hours
Battery Pack Specification:
PVC covered 18650Cells and BMS pack
SANYO GA 3500
Charging Model CC/CV
Charge Temperature 0-45°C
Discharge Temperature -20-55°C
Charger Voltage: 54.6V
4.5kg
Dimensions 370 x 110 x 90 mm

Rack Battery 48V 12.8Ah

Rack style Li-Ion pack in stylish thin alloy case with auto connect socket, with charge indicator, security lock and accessories.
The rack battery is a battery you can mount on bike’s rack.  The battery can be locked to its support or un-lock and slide out to remove. The rack is not included. can be purchased here: https://ebikebc.com/product/rack-for-battery/
Li-Ion 48V  12.8Ah
Energy : 615Wh
Max Power: 1500W
Standard recharge time 7 hours
Battery Pack Specification:
